Name: Pisces FI Series Swimming Pool Heat Pumps
Brand: AMITIME ELECTRIC CO.,LTD.
Availability: InStock

Features of Pisces FI Series Swimming Pool Heat Pumps

Wide working range: -15"C(optional) ~ 43°C

Full inverter technology: Inverter compressor and DC fan motor

No screws design, strong metal with protective coating, easy to maintenance. Two bendings in the right and left side, make the unit brief but ingenious

±0.2°C precision temp. control brings you a more enjoyable and cozy experience

WIFI & APP functions: As standard, the WIFI module makes smart APP remote control available, so you could monitor and adjust the unit operations for real-time and conveniently.

Fan grill anti-rust: Electrophoresis technology for anti-rust and anti-corrosion

Easy maintenance: 7 mins to dismount and install a new controller, save quite a lot energy for after sales

Details of Pisces FI Series Swimming Pool Heat Pumps

Model		Pisces FI 07	Pisces FI 10	Pisces FI 13	Pisces FI 15	Pisces FI 20	Pisces FI 20Tri	Pisces FI 24	Pisces FI 24Tri	Pisces FI 30	Pisces FI 30Tri
Model		Taurus FI 07	Taurus FI 10	Taurus FI 13	Taurus FI 15	Taurus FI 20	Taurus FI 20Tir	Taurus FI 24	Taurus FI 24Tir	Taurus FI 30	Taurus FI 30Tir
Performance at Air 26℃, Water 26℃
Capacity	kW	6.7	8.63	11.9	13.8	19.4	19.4	23.8	23.8	30.5	30.5
COP	W/W	6.36	6.1	5.78	5.47	5.58	5.58	5.35	5.35	5.43	5.43
Power input	KW	1.05	1.44	2.06	2.53	3.48	3.48	4.45	4.45	5.63	5.63
Performance at Air 15℃, Water 26℃
Capacity	kW	5.1	6.38	8.66	10.74	14.7	14.7	17.6	17.6	24	24
COP	W/W	4.87	4.76	4.59	4.63	4.59	4.59	4.49	4.49	4.54	4.54
Power input	kW	1.04	1.34	1.88	2.32	3.2	3.2	3.93	3.93	5.29	5.29
Performance at Air 35℃, Water 30℃
Capacity	kW	2.72	4.2	5.37	6.73	9.96	9.96	12.2	12.2	15.2	15.2
COP	W/W	4.66	3.9	4.1	4.08	3.41	3.41	2.95	2.95	2.78	2.78
Power input	kW	0.58	1.08	1.31	1.64	2.91	2.91	4.14	4.14	5.47	5.47
Performance at Air 2℃, Water 26℃
Capacity	kW	3.72	3.76	5.13	6.13	9.96	9.96	12.4	12.4	17.5	17.5
COP	W/W	3.99	3.29	3.09	3.03	3.41	3.41	3.68	3.68	3.65	3.65
Power input	kW	0.93	1.14	1.65	2.02	2.91	2.91	3.38	3.38	4.79	4.79
Performance at Air -7℃, Water 26℃
Capacity	kW	2.78	2.65	4.77	5.12	8.68	8.68	10.3	10.3	13.1	13.1
COP	W/W	3	3.12	2.69	3.2	3.16	3.16	3.18	3.18	2.99	2.99
Power input	kW	0.91	0.85	1.77	1.6	2.74	2.74	3.24	3.24	4.39	4.39
Power supply		230V/1 Ph/50Hz					380-420V/3 Ph/50Hz	230V/1 Ph/50Hz	380-420V/3 Ph/50Hz	230V/1 Ph/50Hz	380-420V/3 Ph/50Hz
Max power input	kW	1.8	2	3	3.5	4	6.48	5.3	6.48	6.2	10
Max current Input	A	8	9	13	16	17.5	11	23	11	27	15
Rated power	kW	1.04	1.34	1.88	2.32	3.2	3.2	3.93	3.93	5.29	5.29
Rated current	A	4.5	5.8	8.2	10	13.9	5.4	17.1	6.67	23	8.98
Fuse or circuit breaker(A)	A	10	11	15	18	20	13	28	13	36	17
Water flow	m³/h	3	3	3.87	4.73	6.45	6.45	7.75	7.75	10.33	10.33
Noise at 10m	dB(A)	19-31	21-34	20-34	23-36	27-37	27-37	29-39	32-42	29-39	32-42
Net/Package dimensions	mm	823×375×646			906×375×646	1104×395×746		1133×545×846
Net/Package dimensions	mm	894×405×800			974×405×800	1174×425×881		1165×575×1025
Container quantity（40HQ）	Pcs	213	213	213	195	141	141	80	80	80	80
Net/poids weight	kg	42.5/52	44.5/54	49.5/58	55.8/65.8	70/83	73.5/86.5	88.5/105.8	92/109.3	96/114	96/114
Advised pool volume	m³	15-30	22-43	30-56	37-68	45-85	45-85	54-90	54-90	72-120	72-120
Advised Pool Volume (fabricant)	m³	20	28	36	45	60	60	72	72	96	96
Heating temperature range	℃	15～40℃
Cooling temperature range	℃	8～28℃
Operating range	℃	-7～43℃
WIFI		YES
The specifications are subject to change without prior notice. For actual specifications of unit, please refer to the stickers on the unit.
